SS 懸浮固體水質分析儀
Lovibond/德國
產品編號:MD100-SS
產品簡述:
- 德國水質領導品牌Lovibond製造,高品質保證。
- 機體精巧的設計,方便您攜帶檢測。
- 將樣品放入試管中即可自動顯示濃度,簡單方便。
- 自動零點校準,校準模式指示燈顯示。
- 日澤總代理,德國 Lovibond 原廠直接供應
檔案下載
MD 100 是水質分析的專用儀器。高精度光學系統,頂級品質干涉濾光片,採用LED光源,具有長期穩定性。取代傳統加熱迴流法,利用德國原廠的封密式試管,搭配不同的測定藥劑,將樣品放入試管中即可自動顯示濃度。
檢測步驟
- 按下[On/Off]鍵。
- 將測定藥劑置入裝滿水樣測定瓶中,並旋緊瓶蓋。
- 將裝好水樣的圓形測定瓶放入測定室,確認標誌對齊。
- 蓋上測定室外蓋。
- 按下[↲]鍵開始測量。
- 15秒即可得知測定結果。
產品規格
左右尚有資訊
測定範圍 | 10 - 750 mg/L TSS | 測定原理 | Turbidity / Attenuated Radiation Method |
光源波長 | 高輝 LED 430 nm Δλ = 5 nm 530 nm Δλ = 5 nm 560 nm Δλ = 5 nm 580 nm Δλ = 5 nm 610 nm Δλ = 6 nm 660 nm Δλ = 5 nm |
||
波長確度 | ± 1 nm | 自動關機 | 具有自動關機功能 |
測定精度 | 3 % FS (T = 20 °C – 25 °C) | 環境條件 | 溫度:5-40 ℃ 相對濕度: 30-90% |
操作面板 | 耐酸和耐溶劑的防水型觸摸式鍵盤 | 認證 | CE 認證 |
顯示屏 | 背光圖形顯示 | 防水性 | IP 68 |
記憶功能 | 16組記憶資料 | 尺寸 | 155 x 75 x 35 mm |
電源 | 3 號電池四個 | 重量 | 260 g |
MD100 其餘項目產品列表
左右尚有資訊
類型 | 產品名稱 | 檢測項目及範圍 | 產品編號 |
---|---|---|---|
Single |
MD 100 Aluminium, tablet reagents
|
Aluminium PP 0.01 - 0.25 mg/L Al Aluminium T 0.01 - 0.3 mg/L Al |
276200 |
Single |
MD 100 Aluminium, powder reagents
|
Aluminium PP 0.01 - 0.25 mg/L Al Aluminium T 0.01 - 0.3 mg/L Al |
276205 |
Single |
MD 100 Ammonia, tablet reagents
|
Ammonia PP 0.01 - 0.8 mg/L N Ammonia T 0.02 - 1 mg/L N |
276060 |
Single |
MD 100 Ammonia, powder reagents
|
Ammonia PP 0.01 - 0.8 mg/L N Ammonia T 0.02 - 1 mg/L N |
276065 |
Single |
MD 100 Chlorine, tablet reagents
|
Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) |
276000 |
Single |
MD 100 Chlorine, liquid reagents
|
Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) |
276005 |
Single |
MD 100 Chlorine DUO, tablet reagents
|
Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine PP 0.02 - 2 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) |
276020 |
Single |
MD 100 Chlorine DUO, powder reagents
|
Chlorine HR PP 0.1 - 8 mg/L Cl2 a) Chlorine PP 0.02 - 2 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) |
276025 |
Single |
MD 100 Chlorine, powder reagents
|
Chlorine HR PP 0.1 - 8 mg/L Cl2 a) Chlorine PP 0.02 - 2 mg/L Cl2 a) |
276010 |
Single |
MD 100 Chlorine HR (potassium iodide), tablet reagents
|
Chlorine HR (KI) T 5 - 200 mg/L Cl2 | 276170 |
Single |
MD 100 Chlorine dioxide, tablet reagents
|
Chlorine dioxide PP 0.04 - 3.8 mg/L ClO2 Chlorine dioxide T 0.02 - 11 mg/L ClO2 |
276030 |
Single |
MD 100 Chlorine dioxide, powder reagents
|
Chlorine dioxide PP 0.04 - 3.8 mg/L ClO2 Chlorine dioxide T 0.02 - 11 mg/L ClO2 |
276035 |
Single |
MD 100 Chloride, tablet reagents
|
Chloride T 0.5 - 25 mg/L Cl- Chloride T 5 - 250 mg/L Cl- i) |
276180 |
Single |
MD 100 COD, tube tests
|
COD HR TT 200 - 15000 mg/L CODb) COD LMR TT 15 - 300 mg/L CODb) COD LR TT 3 - 150 mg/L CODb) COD MR TT 20 - 1500 mg/L CODb) |
276120 |
Single |
MD 100 Iron, tablet reagents
|
Iron (TPTZ) PP 0.02 - 1.8 mg/L Fe Iron PP 0.02 - 3 mg/L Feg) Iron T 0.02 - 1 mg/L Fe |
276050 |
Single |
MD 100 Iron TPTZ, powder reagents
|
Iron (TPTZ) PP 0.02 - 1.8 mg/L Fe Iron PP 0.02 - 3 mg/L Feg) Iron T 0.02 - 1 mg/L Fe |
276055 |
Single |
MD 100 Iron, powder reagents
|
Iron (TPTZ) PP 0.02 - 1.8 mg/L Fe Iron PP 0.02 - 3 mg/L Feg) Iron T 0.02 - 1 mg/L Fe |
276056 |
Single |
MD 100 Fluoride (without reagents)
|
Fluoride L 0.05 - 2 mg/L F- | 276090 |
Single |
MD 100 Hardness, total, tablet reagents
|
Hardness total HR T 20 - 500 mg/L CaCO3 i) Hardness total T 2 - 50 mg/L CaCO3 |
276190 |
Single |
MD 100 Urea, tablet reagents
|
Urea T 0.1 - 2.5 mg/L Urea Urea T 0.2 - 5 mg/L Ureai) |
276210 |
Single |
MD 100 Hazen/A.P.H.A., no reagents required
|
Hazen 24 10 - 500 mg/L Pt | 276160 |
Single |
MD 100 Copper, tablet reagents
|
Copper PP 0.05 - 5 mg/L Cu Copper T 0.05 - 5 mg/L Cua) |
276080 |
Single |
MD 100 Copper, powder reagents
|
Copper PP 0.05 - 5 mg/L Cu Copper T 0.05 - 5 mg/L Cua) |
276085 |
Single |
MD 100 Manganese LR, tablet reagents
|
Manganese HR PP 0.1 - 18 mg/L Mn Manganese LR PP 0.01 - 0.7 mg/L Mn Manganese T 0.2 - 4 mg/L Mn |
276100 |
Single |
MD 100 Manganese LR, powder reagents
|
Manganese HR PP 0.1 - 18 mg/L Mn Manganese LR PP 0.01 - 0.7 mg/L Mn Manganese T 0.2 - 4 mg/L Mn |
276105 |
Single |
MD 100 Manganese HR, powder reagents
|
Manganese HR PP 0.1 - 18 mg/L Mn Manganese LR PP 0.01 - 0.7 mg/L Mn Manganese T 0.2 - 4 mg/L Mn |
276106 |
Single |
MD 100 Molybdenum LR, powder reagents/ tablet reagents
|
Molybdate HR PP 0.3 - 40 mg/L Mo Molybdate LR PP 0.03 - 3 mg/L Mo Molybdate T 0.6 - 50 mg/L MoO4 |
276140 |
Single |
MD 100 Molybdenum HR, powder reagents
|
Molybdate HR PP 0.3 - 40 mg/L Mo Molybdate LR PP 0.03 - 3 mg/L Mo Molybdate T 0.6 - 50 mg/L MoO4 |
276141 |
Single |
MD 100 Molybdenum, tablet reagents
|
Molybdate HR PP 0.3 - 40 mg/L Mo Molybdate LR PP 0.03 - 3 mg/L Mo Molybdate T 0.6 - 50 mg/L MoO4 |
276142 |
Single |
MD 100 Phosphate, tablet reagents
|
Phosphate LR T 0.02 - 1.3 mg/L P Phosphate PP 0.02 - 0.8 mg/L P |
276040 |
Single |
MD 100 Phosphate, powder reagents
|
Phosphate LR T 0.02 - 1.3 mg/L P Phosphate PP 0.02 - 0.8 mg/L P |
276045 |
Single |
MD 100 Silica, tablet reagents
|
Silicate HR PP 1 - 90 mg/L SiO2 Silicate LR PP 0.1 - 1.6 mg/L SiO2 Silicate T 0.05 - 4 mg/L SiO2 |
276110 |
Single |
MD 100 Silica LR, powder reagents
|
Silicate HR PP 1 - 90 mg/L SiO2 Silicate LR PP 0.1 - 1.6 mg/L SiO2 Silicate T 0.05 - 4 mg/L SiO2 |
276115 |
Single |
MD 100 Silica HR, powder reagents
|
Silicate HR PP 1 - 90 mg/L SiO2 Silicate LR PP 0.1 - 1.6 mg/L SiO2 Silicate T 0.05 - 4 mg/L SiO2 |
276116 |
Single |
MD 100 Suspended solids, no reagents required
|
Suspended solids 24 10 - 750 mg/L TSS | 276150 |
2in1 |
MD 100 Chlorine, pH, tablet reagents (OTZ)
|
Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278020 |
2in1 |
MD 100 Chlorine, pH, liquid reagents (OTZ)
|
Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278025 |
2in1 |
MD 100 Chlorine, pH, powder reagents for chlorine
|
Chlorine HR PP 0.1 - 8 mg/L Cl2 a) Chlorine PP 0.02 - 2 mg/L Cl2 a) pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278030 |
3in1 |
MD 100 Chlorine, pH, Cyanuric acid, tablet reagents (OTZ)
|
Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) CyA T 10 - 160 mg/L CyA pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278010 |
3in1 |
MD 100 Chlorine, pH, Cyanuric acid, liquid reagents for Chlorine and pH (OTZ)
|
Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) CyA T 10 - 160 mg/L CyA pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278015 |
3in1 |
MD 100 Chlorine, pH, Alkalinity-m, tablet reagents (OTZ)
|
Alkalinity-m T 5 - 200 mg/L CaCO3 Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278060 |
3in1 |
MD 100 Chlorine, pH, Alkalinity-m, liquid reagents for Chlorine and pH (OTZ)
|
Alkalinity-m T 5 - 200 mg/L CaCO3 Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278065 |
2in1 |
MD 100 Chlorine LR, Chlorine HR, Chlorine dioxide, tablet reagents
|
Chlorine dioxide T 0.02 - 11 mg/L ClO2 Chlorine HR (KI) T 5 - 200 mg/L Cl2 Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) |
278000 |
4in1 |
MD 100 Chlorine, pH, Cyanuric acid, Alkalinity-m, tablet reagents (OTZ)
|
Alkalinity-m T 5 - 200 mg/L CaCO3 Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) CyA T 10 - 160 mg/L CyA pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278070 |
4in1 |
MD 100 Chlorine, pH, Cyanuric acid, Alkalinity-m, liquid reagents for Chlorine and pH (OTZ)
|
Alkalinity-m T 5 - 200 mg/L CaCO3 Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) CyA T 10 - 160 mg/L CyA pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278075 |
4in1 |
MD 100 Chlorine DUO, Chlorine HR, pH, Alkalinity-m, Calcium hardness (OTZ)
|
Alkalinity-m T 5 - 200 mg/L CaCO3 Chlorine HR (KI) T 5 - 200 mg/L Cl2 Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine MR PP 0.02 - 3.5 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) Hardness Calcium (B) T 20 - 500 mg/L CaCO3 pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278160 |
5in1 |
MD 100 Chlorine, pH, Cyanuric acid, Alkalinity-m, Calcium hardness, tablet reagents (OTZ)
|
Alkalinity-m T 5 - 200 mg/L CaCO3 Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) CyA T 10 - 160 mg/L CyA Hardness Calcium (B) T 20 - 500 mg/L CaCO3 pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278080 |
6in1 |
MD 100 Chlorine, Bromine, pH, Cyanuric acid, Alkalinity-m, Calcium hardness, tablet reagents (OTZ)
|
Alkalinity-m T 5 - 200 mg/L CaCO3 Bromine T 0.05 - 13 mg/L Br2 Chlorine HR T 0.1 - 10 mg/L Cl2 a) Chlorine L 0.02 - 4.0 mg/L Cl2 a) Chlorine T 0.01 - 6.0 mg/L Cl2 a) CyA T 10 - 160 mg/L CyA Hardness Calcium (B) T 20 - 500 mg/L CaCO3 pH value L 6.5 - 8.4 pH-value T 6.5 - 8.4 |
278090 |
Boiler Water |
MD 100 Boiler Water
|
Aluminium PP 0.01 - 0.25 mg/L Al Chloride L (B) 0.5 - 20 mg/L Cl- Copper T 0.05 - 5 mg/L Cua) DEHA PP 0.02 - 0.5 mg/L DEHA Hydrazine P 0.05 - 0.5 mg/L N2H4 Iron LR L (A) 0.03 - 2 mg/L Fe Oxygen dissolved C 10 - 800 µg/L O2 c) Phosphate HR L 5 - 80 mg/L PO4 Polyacrylate L 1 - 30 mg/L Polyacryl Silicate HR PP 1 - 90 mg/L SiO2 |
276230 |
Cooling Water |
MD 100 Cooling Water
|
16 Parameters | 276240 |
常見問題
Q1. 請問MD100/MD200機型可檢測項目為何?→ MD100/MD200機型為單一功能分析儀,機型多樣包含單一項目、二合一、三合一等,如有需求歡迎洽詢,將由專責業務顧問為您推薦適合機型及項目。
Q2. 請問儀器需要校正嗎? 校正頻率約?
→ 儀器建議每年做一次光源檢查及校正,使用原廠標準波長色瓶檢查光源,另外會針對儀器功能進行檢查調整。
Q3. 每個檢測項目是否需要有配合的檢測藥劑?
→ 目前除懸浮固體及濁色度外,其他項目需搭配相關試劑使用測定,詳細規格及使用歡迎洽詢。
產業應用
冷卻水 / 原水處理 / 污水處理 / 泳池水處理 / 泳池水質控制 / 消毒控制 / 電鍍 / 鍋爐水 / 飲用水處理相關產品
